Khoom zoo
Cov khoom siv sib txawv
Peb cov ntaub ntawv tseem ceeb suav nrog High-Speed Steel (HSS), Cobalt High-Speed Steel (M35/M42), Powder Metallurgy High-Speed Steel (HSS-E-PM), thiab Carbide. Ntawm cov no, Carbide kais dej khav theeb hardness ncav cuag HRC 89 thiab txiav ceev 4 mus rau 5 npaug sai dua li cov HSS kais dej; thaum machining cov ntaub ntawv xws li txhuas alloys, lawv cov cuab yeej siv tau ntev mus txog ntawm 5,000 thiab 8,000 qhov. Hmoov Metallurgy High-Speed Steel, tus yam ntxwv los ntawm nws cov khaub ncaws thiab ntom microstructure, muaj 80% ntau dua hnav tsis kam piv rau cov khoom siv ib txwm siv, ua rau nws zoo tshwj xeeb tshaj yog rau kev siv lub tshuab hardened steel, stainless hlau, thiab siab - kub alloys.
Kev tsim kho tshiab Modular
Siv lub patented interface los ua ke lub taub hau carbide xov nrog steel shank, qhov tsim no muab ob qho tib si tshwj xeeb lub neej thiab kev txiav ceev. Ua raws li kev siv cov tshuaj no, qee tus neeg muag khoom tsheb pom lawv cov kev txiav ceev nce ntawm 30 m / min mus rau 40 m / min, thaum lub neej kev pab cuam ntawm ib lub taub hau kais skyrocketed los ntawm 9,500 qhov mus rau 225,000 qhov, uas ua rau tag nrho cov nqi txuag ntawm 25%.
High -Cov Txheej Txheem Ua Haujlwm
PVD coatings-xws li TiN, TiCN, TiAlN, thiab CrN-tseem ceeb heev txhim khu kev hnav tsis kam thiab txo kev sib txhuam coefficient, yog li ncua lub neej ntawm cov cuab yeej los ntawm qhov zoo ntawm 3 mus rau 8 zaug. TiCN txheej, tshwj xeeb tshaj yog, sib txuas cov tawv tawv nrog qis- kev sib txhuam cov khoom, ua rau nws zoo heev rau kev tapping thiab xov- ua haujlwm.
Ntau hom Flute Geometry
Ncaj-flute kais muaj ntau yam khoom siv; kauv flutes pab txhawb nti khiav tawm hauv qhov muag tsis pom; thiab kauv-taw tes kais dej yog qhov zoo tagnrho rau kev siab - nrawm txiav hauv - qhov. Kev tsim cov kais dej, uas tsim cov xov los ntawm chipless yas deformation, yog tsim rau cov ntaub ntawv ductile xws li txhuas thiab tooj liab, ua cov xov ntawm lub zog zoo dua.
Kev tsim khoom
Hmoov Metallurgy Blank Kev Npaj
Hlau molten nyob rau hauv ib tug siab - zaus induction rauv yog atomized rau hauv cov hmoov siv siab - siab gas jets, ces sintered nyob rau hauv siab kub thiab siab los ua ib tug tuab dawb paug. Cov txheej txheem no tshem tawm cov carbide sib cais thiab ua kom lub cev tsis sib xws, yog li txhim kho tus kais dej kev ntseeg tau thiab kev sib tsoo.
Daim ntawv sib tsoo
A 5-axis CNC cuab tam grinder yog siv rau precision-sib tsoo lub helical flutes, txiav ntug, thiab sizing seem. Rau kev xaiv siab -kawg kawg, txiav- ntug precision yog tswj nyob rau hauv ± 0.005 hli, thiab xov kam rau ua tiav ISO 3H / 5H qib, ua tau raws li cov kev xav tau nruj ntawm precision-tseem ceeb sectors xws li automotive thiab aerospace industries.
Kev kho cua sov thiab kev kho deg
Los ntawm kev tsim tshwj xeeb alloying thiab cov txheej txheem kho cua sov ua kom zoo, cov teeb meem xws li kev sib tsoo kub hnyiab tau raug daws tau zoo. Tom qab ntawd, cov kais dej tau txais kev kho PVD txheej-xws li TiN thiab TiAlN- txhawm rau txhim kho lawv cov hnav tsis kam thiab lubrication.
